AsyncAPI 3.1 for your Sume webhook receiver: a 29-line spec

Write an AsyncAPI 3.1.0 document with one channel for your webhook path, a receive operation, and a message whose headers are x-sume-webhook-timestamp and x-sume-webhook-signature and whose payload has event and job_id. The AsyncAPI reference (read 2026-10-10) lists 3.1.0 as the current version and defines action as send or receive, which is how a receiver is described in version 3.

The document below parses cleanly with the @asyncapi/parser package and reports version 3.1.0. It documents your receiver. It is not a Sume-published spec; Sume documents webhooks in prose and in its OpenAPI file.

The document

The three event names come from the Webhooks docs: job.completed, job.failed and job.canceled. Sume sends terminal job events only, with no progress or partial deliveries, so the payload enum has exactly those three values. status is OK for a completed job and ERROR for failed and canceled ones, which carry an error object that this short sketch leaves out.

asyncapi: 3.1.0
info: {title: Sume job webhooks, version: 1.0.0}
channels:
  sumeJobs:
    address: /sume/webhook
    messages:
      jobTerminal: {$ref: '#/components/messages/jobTerminal'}
operations:
  receiveJobEvent:
    action: receive
    channel: {$ref: '#/channels/sumeJobs'}
    messages:
      - $ref: '#/channels/sumeJobs/messages/jobTerminal'
components:
  messages:
    jobTerminal:
      headers:
        type: object
        required: [x-sume-webhook-timestamp, x-sume-webhook-signature]
        properties:
          x-sume-webhook-timestamp: {type: string}
          x-sume-webhook-signature: {type: string}
      payload:
        type: object
        required: [event, job_id]
        properties:
          event: {enum: [job.completed, job.failed, job.canceled]}
          job_id: {type: string}
          status: {enum: [OK, ERROR]}

What the document gives you

What it cannot express

AsyncAPI describes shapes, not the signature algorithm, the 5-minute replay window, the 10-attempt retry schedule or the job_id idempotency rule. Put those in the description of the operation, and test them in code. A schema check that passes on a forged body is not security, which is why the verifier stays in your handler and refuses an empty secret.

During a secret rotation the signature header can carry several comma-separated sume-v1= entries, so type the header as a string, not as a single hex value.

Use it for contract tests

Generate a mock sender from the document, post sample payloads to your handler, and assert it answers 2xx for a valid signature and 401 for a bad one. Redelivery after your handler stored the event must not create a second record, so add a case that sends the same job_id twice. The document stays useful as the single page a new teammate reads before touching the receiver.
